6.

Components of the Excel G-Modular

In this chapter the different components of the Excel G-Modular are described. On the wheelchair are a number
of components present which are adjustable. If you want to add or remove any of its components, make any
adjustments of replace components, you should always follow the instructions described in this user manual.
6.1

Folding and unfolding the wheelchair

To fold or unfold the wheelchair, there are some steps you should follow. When folding and unfolding the
wheelchair you should always be careful so that the wheelchair does not get damaged.
6.1.1

Folding the wheelchair

If you want to fold the wheelchair, please follow the following steps.
• Before you can fold the wheelchair, the footrests should be raised. On photo 1 you can see how footrests
are when the wheelchair is unfolded. By folding the foot rests upwards (photo 2), you can in turn fold the
wheelchair. On photo 3 you see the foot rests when they are folded upwards;
• To fold the wheelchair, you must first push the orange button on the tension bar and push the tension bar
down, like shown on photo 4 and photo 5;
• Now, you can lift the seat by pulling the seat sling up, as you can see on photo 6;
• Finally, on photo 7 you see the wheelchair folded.
EXCEL G-MODULAR | PHOTO 1
EXCEL G-MODULAR | PHOTO 5
Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com
User Manual | Excel G-Modular
EXCEL G-MODULAR | PHOTO 2
EXCEL G-MODULAR | PHOTO 6
© 2015 Excel, part of Van Os Medical B.V.
EXCEL G-MODULAR | PHOTO 3
EXCEL G-MODULAR | PHOTO 7
16
EXCEL G-MODULAR | PHOTO 4
