54 A B: A
PPENDIX DMINISTERING
ATM
Table 8 describes the fields in the port displays:
Table 8 Fields in the ATM Ports Displays
Field Description
bandwidth Total bandwidth available for port (in bits per second)
cfgVPCx Current number of virtual path connections
cfgVCCs Current number of virtual channel connections
hecErrors Header Error Checksum count
lastChange Last time the link state of the port changed since the last reboot
linkStatus State of link
maxVCCs Maximum number of possible virtual channel connections
maxVPCs Maximum number of possible virtual path connections
maxVCIbits Maximum number of bits available to represent a Virtual
Channel Identifier
maxVPIbits Maximum number of bits available to represent a Virtual Path
Identifier
mediaType Type of physical connection media
ocdEvents Number of times an out-of-cell delineation was detected
operStatus Current state of port
portLabel Label for the physical port
reqStatus Requested state of port
rxCells Number of cells received
rxCellsDropped Number of cells received but thrown away
tcAlarm Transmission convergence alarm
transType Type of transmission sublayer
txCellDiscards Number of cells thrown out after attempting to transmit
txCells Number of cells transmitted
uniType Type of User-Network Interface (public or private)
uniVersion UNI specification implemented
