Table 7 describes the fields provided in the UNI Management Entity
displays.
Table 7 Fields in the UME Display
Attribute Description
connCount Number of times port has successfully connected since last
reboot
discCount Number of times port has disconnected since last reboot
dropRxPdus Number of protocol data units (frames) received but not
processed
reqState Requested connection state for management access and address
registration (connected or disconnected)
reqVci Requested virtual channel identifier. This value takes effect after
you disable and then enable the port.
reqVpi Requested Virtual Path Identifier. This value takes effect after you
disable and then enable the port.
rxPdus Number of protocol data units (frames) received
txPdus Number of protocol data units (frames) transmitted.
state Current connection state for management access and address
registration. Possible values:
Connected — Address registration has been successfully
completed
Connecting — Circuit is up, but the port has not successfully
completed address registration
Disconnected — Either the reqState has been set to this state
or the circuit is down
Disconnecting — Address registration has been terminated
but the circuit is still up
vci Current virtual channel identifier
vpi Current virtual path identifier
