TROUBLESHOOTING

Troubleshooting
PROBLEM
The transceiver does
not turn ON.
Little or no sound
comes from the
speaker.
You cannot transmit.
You cannot use the
keypad to enter the
frequency or select
the memory channel.
Scan does not start.
No beep sounds.
D Fuse replacement
If the fuse blows or the transceiver stop working when using
the optional CP-23L CIGARETTE LIGHTER CABLE, correct
the source of the problem. Then replace the damaged fuse
with a new rated one (FGB 4 A), as shown to the right.
POSSIBLE CAUSE
• The battery is exhausted.
• The battery pack is not correctly attached.
• The CP-23L's fuse is blown.
• Squelch level is set too high.
• Volume level is set too low.
• NAV band frequency is set.
• Weather channel or other non-
transmittable channel is selected.
• No frequency is entered into the
selected channel.
• The battery is exhausted.
• The keypad is locked.
• No Memory channels in the selected
group are tagged.
• The squelch is open.
• Nothing is entered in the Memory
channels.
• The Key beep is set to OFF.
• The audio output level is low.
• Recharge the battery pack.
• Correctly reattach the battery pack.
• Repair the problem, and then replace
the fuse.
• Adjust the squelch level.
• Adjust the volume level.
• Set a COM band frequency.
• Select a transmittable channel.
• Enter a frequency into the Memory
channel.
• Recharge the battery pack.
• Hold down [
unlock the keypad.
• Tag memory channels.
• Adjust the squelch level.
• Enter frequencies into the Memory
channels.
• Push [FUNC], and then push
[8]/[BEEP] to turn ON the beep.
• Rotate [VOL] to adjust the audio
output level.
18
SOLUTION
] for 2 seconds to
Fuse 4 A
REF.
p. 6
p. 2
p. 18
p. 4
p. 4
p. 7
p. 7
p. 9
p. 6
p. 4
p. 8
p. 4
p. 9
p. 4
p. 4
