One Speed Self-Tailing Winch
I Required Tools
Screwdriver
Plastic Head Hammer or Mallet
Small Knife
Brush
Rags
Solvent
Oil
Grease
I Parts List
008
038
6669
6143
6428
27005
27006
27059
27778
27779
27780
27790
27791
28167
32532
37340
37383
37589
38597
39123
42784
42787
703192
942786
942783
939121
I Suggested Service Kits
BK4512
BK4513
When ordering parts, please include a
"B" before each number (i.e. B008).
Winch Parts
Installation
Service
Pawl
Pawl Spring
Screw
Top Screw
Screw
Spindle
Bearing Spacer
Cover Plate
Ratchet Gear
Gear
Gear Shaft
Handle Socket
Plastic Washer
Red Line Ring
Top Cap
Upper Jaw
Spring Support
Chrome Stripper Arm
Spring
Bronze Stripper Arm
Lower Jaw
Center Stem
Bearing
Aluminum Drum
Chrome Drum
Bronze Drum
10
008 Pawls
10
038 Springs
100ml Grease
