16.2
Two Speed Winch
Winch Parts
Installation
Service
Required Tools
Screwdriver
Plastic Head Hammer or Mallet
Small Knife
Brush
Rags
Solvent
Oil
Grease
Parts List
008
Pawl
038
Pawl Spring
6143
Top Screw
6428
Screw
27006
Bearing Spacer
27059
Cover Plate
27776
Center Stem
27777
Spindle
27778
Ratchet Gear
27779
Gear
27780
Gear Shaft
27791
Plastic Washer
28167
Red Line Ring
30607
Ratchet Head
703192
Bearing
927773
Aluminum Drum
928532
Chrome Drum
Suggested Service Kits
BK4512
10
008 Pawls
10
038 Springs
BK4513
100 ml Grease
When ordering parts, please include a
"B" before each number (i.e. B008).
