XVME-240 Manual
October, 1984
Signal
Mnemonic
+5v
G N D
BACKPLANE CONNECTOR P2
The following table lists the P2 pin assignments by pin number order. (The connector
consists of three rows of pins labeled A, B, and C.)
Table B-3. P2 - VMEbus
Connector
and
Pin Number
2G: 2,12
22,31
ALL OTHER PINS NOT USED
Table B-4. P2 Pin Assignments
Signal Identification
Signal Name and Description
+5 Vdc Power - Used by system
logic circuits.
Ground
B-6
--
--
--
--
