XVME-240 Manual
October, 1984
INTRODUCTION
The purpose of this Appendix is to define XYCOM's
XVME I/O modules.
XVME I/O modules in order to provide a simpler and more consistent method of
programming for the entire module line. The I/O Architecture specifies the logical
aspects of bus interfaces, as
in the VMEbus specifications. The module elements which are standardized by the
XYCOM I/O Architecture are the following:
Module Addressing - - Where a module is positioned in the I/O address
space and how software can read from it or write to it.
Module Identification -- How software can identify which modules are
installed in a system.
Module Operational Status -- How the operator can (through software)
determine the operational condition of specific modules within the system.
Interrupt Control -- How software is able to control and monitor the
capability of the module to interrupt the system
Communication between Modules -- How master (host) processors and
intelligent I/O modules communicate through shared global memory or the
dual-access RAM on the I/O modules.
The I/O Kernel -- How intelligent and non-intelligent "kernels" facilitate
the operation of all XYCOM I/O modules.
MODULE ADDRESSING
All XYCOM I/O modules are designed to be addressed within the VMEbus-defined 64K
short I/O address space. The restriction of I/O modules to the short I/O address space
provides separation of program/data address space and the I/O address space. This
convention simplifies software design and minimizes hardware and module cost, while
at the same time, providing 64K of address space for I/O modules.
Base Addressing
Since each I/O module connected to the bus must have its own unique base address, the
base addressing scheme for XYCOM VME I/O modules has been designed to be jumper-
selectable. Each XVME I/O module installed in the system requires at least a 1K byte
block of the short I/O memory. This divides the 64K short I/O address space into 64
Thus, each I/O module has a base address which starts on a 1K
1K segments.
boundary. As a result, the XYCOM I/O modules have all been implemented to decode
Appendix A
XYCOM STANDARD I/O ARCHITECTURE
This Standard I/O Architecture has been incorporated on all
opposed to the "physical" or electrical aspects as defined
Standard I/O Architecture for
A-l
