INTERRUPT MASK REGISTER Base Address + 83H)
Bit Bit
Bit
7 6 5
Writing a "1" will "pass" an interrupt.
Writing a
For example, in order to mask out all latched interrupts except those latched on
Interrupt Input 3, a value of 04H must be written to the module base address + 83H.
This will put a "1" in the fourth bit (interrupt input 3) and "0"s in all other bits. As
long as this "mask"
through" are those occurring on interrupt input 3. The only way to change the mask is
to write a new value to the module base address + 83H.
Writing FFH to the Interrupt Mask Register would pass all latched
writing 00H to the register would mask out all latched interrupts.
The Interrupt Mask Register is set to all " 0 " s (all
interrupts
SYSRESET or Soft Reset.
enable interrupts, the user software/firmware will
have to write the correct masks to the Mask Reg-
ister
3.3.7 Interrupts Pending Register (Base Address + 82H)
The contents of this "read only" register can be studied by user-provided software/
firmware to determine if there are latched interrupts which have passed through the
interrupt mask (if any) and are waiting to be serviced. This register directly relates to
Bit 2 of the Status/Control register (refer to Section 3.3.2). If any bit in this register
Bit
is set, 2 of the Status/Control Register will also be set.
Status/Control Register shows if there are any pending interrupts at all, and the
Bit
Bit Bit
4 3 2
" 0 "
will mask out an interrupt.
Figure 3-6. Interrupt Mask Register
is in the register the only latched interrupts that will be "passed
masked out) immediately following
l
Bit Bit
1 0
Interrupt Input Latch 1
Interrupt Input Latch 2
Interrupt Input Latch 3
Interrupt Input Latch 4
Interrupt Input Latch 5
Interrupt Input Latch 6
Interrupt Input Latch 7
NOTE
In order to properly
3-11
interrupts and
Thus, Bit 2 of the -
