Electronic pellet burner controller – NPBC-V3C-1/ NPBC-V4C-1
NPBC-V3C - 1/ NPBC-V4C - 1
FM
Main fan
FSG
Fan for the flue gases
SF
Screw for fuel
SB
Internal screw
PH
Heating installation pump
PWH
Hot water heater pump
IGN
Ignition heater
FC
Fan for cleaning
ACF
Analog controlled fan (Optional)
User Manual / ver 3.8
Outputs
http://www.naturela-bg.com/en/
INPUTS AND OUTPUTS DESCRIPTION
RT
Room thermostat. To this input could be
connected a normally opened or
normally closed contact, with no
additional voltage.
PS
Photo sensor
RB
Reverse burning sensor
B
Boiler temperature sensor
WH
Water heater temperature sensor
PT
pt100 high temperature sensor
OD
Opened door switch (Optional)
LED
Inputs
page 5 of 36
