Electronic pellet burner controller – NPBC-V3C-1/ NPBC-V4C-1

Select Fuel – Select the preset fuel profile settings corresponding to the currently used fuel. All

parameters for each profile must be set from Burning Setup menu in Factory Settings:

Info Fields – Set the parameters to be displayed in the information fields on the main screen from this

menu.

Choose the information to be displayed for each field from the following list:

Flame level – Level of illumination, measured by the photo sensor

•

Exhaust fan – Current speed of the exhaust fan

•

Timers – If there are any active timers, this field shows when is the next action and what is it

•

(on/off)

Power – The current calculated power of the burner

•

Temp DHW – Temperature in the hot water heater

•

Exhaust temp – Temperature of the exhaust gases

•

User Manual / ver 3.8

http://www.naturela-bg.com/en/

Order of the fields

and their numbers

Choose the information

to be displayed

for each field

page 21 of 36
