Electronic pellet burner controller – NPBC-V3C-1/ NPBC-V4C-1
Additional information and statistics
While on main screen, press the right navigation button (►) to access the additional information and
statistics screens.
Statistics charts about the pellet consumption
The first group of information screens is about the pellet consumption. Press the up or down
navigation buttons to browse the charts for the last 4 days, starting with the current day. The horizontal
axis of the full screen histogram is equally divided for 24 hours and the vertical axis represents the
consumed pellets in kilograms. Above the chart is the corresponding date for the currently displayed
information and below is the total consumption for this day:
Information about some of the current parameters
While on Pellet consumption screen, press the right navigation button again to access the next
information screen. It provides information about the boiler's set temperature, the domestic hot water
current temperature, the level of illumination measured by the photo sensor, the temperature of the
exhaust gases, the exhaust fan's current speed and the total pellet consumption since the last reset:
Date format
Indicator for next page
dd/mm/yyyy
To reset the total pellet consumption press and hold the Menu button for more than 2 seconds.
To go back to Pellet consumption charts, press the left navigation button (◄).
User Manual / ver 3.8
http://www.naturela-bg.com/en/
page 14 of 36
