- Page 1 WARNING: Read these instructions before using the machine 10 TONNE HYDRAULIC BENCH PRESS MODEL NO: CSA10BB PART NO: 7614020 OPERATION & MAINTENANCE INSTRUCTIONS GC0913...
-
Page 2: Safety Precautions
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Tools Required
• PTFE tape ACCESSORIES A mandrel set (including storage bracket and pressure plate) is not supplied with the press but is available from your dealer as Clarke part no 7615060. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 4 INVENTORY 1 x Frame 1 x Pump 2 x Base Supports 1 x Pump Handle 1 x Ram with Locking Collar 1 x Hose (attached to pump) 1 x Pressure Gauge 1 x Press Bed (Frame) 2 x Bed Support Pins 2 x Bed blocks (V-blocks) 1 x Fixing Kit containing bolts, washers &...
- Page 5 4. Unfasten the protective end cap and screw the hose to the threaded connection of the hydraulic ram. • We recommend sealing the thread with PTFE tape. Take care not to let any oil escape while connecting the hose. 5. Screw the pressure gauge to the connecting nut on top of the ram cylinder.
-
Page 6: Hydraulic Pump/Ram Operation
9. If obtained, bolt the mandrel storage bracket to the side of the frame using the bolts supplied. 10. Store the mandrels (if obtained) including the adaptor, in their positions on the bracket. 11. Insert the bed support pins into the holes in the columns at the required position. -
Page 7: Fitting The Mandrels Or Pressure Cap
FITTING THE MANDRELS OR PRESSURE CAP Mandrels are available as an adaptor kit, any of which may be connected to the end of the ram using the adaptor. Alternatively, the basic ram pressure cap can be fitted as shown. Secure the pressure cap by tightening the grub screw with a suitable hex key. -
Page 8: Operation
OPERATION 1. Place the workpiece on the bed. It must be completely stable and supported by packing or shims where required. ‘Heel’ blocks (arbor plates) are supplied, which locate on the bed. Place the workpiece on a combination of these to give it stability CAUTION: DO NOT POINT LOAD THESE ACCESSORIES AS THEY ARE NOT DESIGNED TO TAKE THE FULL FORCE OF THE RAM IN ONE SPOT. -
Page 9: Maintenance
Oil should be level with the mark on the dipstick. If necessary top up with CLARKE hydraulic oil, Part No 3050830. This task is carried out with the ram fully retracted. -
Page 10: Troubleshooting
TROUBLESHOOTING Problem Probable Cause Remedy Pump will not work. Dirt on valve seat/warn Bleed pump unit or have seals. unit overhauled with new seals. Pump will not produce Air-lock in system. Open the release valve pressure. and remove the oil filler Pump feels hesitant plug. -
Page 11: Specifications
SPECIFICATIONS Capacity 10 Tonne Dimensions Operating Pressure 10000 PSI 110 mm Ram Travel 183 mm 340 mm Ram Diameter 42 mm 365 mm Net Weight 55 kg 180 mm 183 mm 600 mm (ex pump) 450 mm 1070 mm 80 mm Parts &... -
Page 12: Frame Parts Diagram
FRAME PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 13: Parts Lists
PARTS LISTS FRAME PARTS DESCRIPTION DESCRIPTION Pressure Gauge Washer 8mm Nylon Ring Spring Washer M8 Ram Assembly Hydraulic Hose Bed Support Pins Pump Assembly Bolt M6 x 25 Bolt M6x16 Nut M6 Spring Washer M6 Bolt M10 X 25 Washer M6 Washer M10 Upper Collar Spring Washer M10... -
Page 14: Ram Parts Diagram
RAM PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
