- Page 1 50 TONNE HYDRAULIC PRESS MODEL NO: CSA50FP PART NO: 7615202 OPERATION & MAINTENANCE INSTRUCTIONS WARNING: Read these instructions before using the press GC0516...
-
Page 2: Safety Symbols
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS 1. Due to the weight of the press, lifting equipment and the help of an assistant will be required during installation. Fix the press to the floor using suitable anchor bolts. 2. Before starting work, check for signs of cracked welds, loose or missing bolts, damaged screen, or any other damage. -
Page 4: Unpacking & Inventory
Ensure the press and its components suffered no damage during transit and that all components are present. Should any loss or damage become apparent, please contact your CLARKE dealer immediately. The following items should be present in their packages. 1 x Frame with ram and carriage 4 x Bed Support Pins attached &... -
Page 5: Assembly Procedure
ASSEMBLY WARNING: DUE TO THE WEIGHT OF THE PRESS, LIFTING EQUIPMENT OR THE HELP OF AN ASSISTANT WILL BE REQUIRED DURING INSTALLATION. TOOLS REQUIRED • Wrench/Socket Set • PTFE tape • Hex Keys ASSEMBLY PROCEDURE IMPORTANT: The press must be firmly secured to a firm and level floor using expansion bolts (not supplied). - Page 6 5. Unfasten the protective hose cap (not shown here) and screw the hose onto the connector block. • We recommend sealing the thread with PTFE tape. Take care not to let any oil escape while connecting the hose. 6. Fit the pressure gauge to the union nut on the inside of the frame.
- Page 7 10. Bolt the connecting bars to the operating arm of the pump. Bolt them together as a pair fitting the short spacers in both positions as shown. 11. Bolt the foot pedal to the frame using the long bolt, long spacer, nut and washers.
-
Page 8: Preparation For Use
6. Top up the hydraulic oil to the lower level of the filler plug with CLARKE hydraulic oil, Part No. 3050830. POSITIONING THE PRESSING BED 1. Use the winch to raise the pressing bed into a suitable position. -
Page 9: Positioning The Ram
2. When satisfied that the bed is at the correct height insert the locking pins into their positions and secure with the spring clips. POSITIONING THE RAM 1. Slide the carriage along the cross- beam. 2. Lock it in position with the four sprung locking bolts. -
Page 10: Operation
OPERATION 1. Place the workpiece on the bed. It must be completely stable and supported by packing or shims where required. Pressing plates (bed blocks) are supplied, which locate on the bed. Place the workpiece on these to give it stability. CAUTION: DO NOT POINT LOAD SUCH ACCESSORIES AS THEY ARE NOT DESIGNED TO TAKE THE FULL FORCE OF THE RAM IN ONE SPOT. -
Page 11: Troubleshooting
Probable Cause Remedy Pump will not work Dirt on valve seat/worn Bleed pump unit or have seals. unit overhauled with new seals by your Clarke dealer. Pump will not produce Air-lock. Open the release valve pressure and remove the oil filler Pump feels hesitant plug. -
Page 12: Maintenance
• Oil should be level with the bottom of the hole. If necessary top up with CLARKE hydraulic oil, Part No. 3050830. This task is carried out with the ram fully retracted. • If any rust is apparent it must be removed completely and the paint restored. -
Page 13: Technical Specifications
Collect any oil in a leak proof container and take it to your local waste disposal site. Should hydraulic components become completely unserviceable and require disposal, draw off the oil into an approved container and dispose of the product and the oil according to local regulations. When requesting spare parts, please quote the prefix XXCSA50FP followed by the number on the diagrams/parts lists here. -
Page 14: Frame Assembly Parts Diagram
FRAME ASSEMBLY PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Frame Assembly Parts List
FRAME ASSEMBLY PARTS LIST DESCRIPTION DESCRIPTION Screw Lock Washer Spring Steel Block Screw Pressing Block Collar Screw Spring Joint Lock Washer Ram Assembly Circlip Ram Mounting Plate Axle Screw Small Cable Roller Elbow Safe Guard 3 Frame Safe Guard 4 Circlip Safe Guard Bearing... -
Page 16: Pump Parts List
DESCRIPTION DESCRIPTION Base Support Washer Handle Foot Pedal Washer Bolt Handle Grip Bolt Spring Bolt Winch Mounting Plate Pump Assembly Wire Rope Pump Guard Wire Rope Hex Head Machine Screw PUMP PARTS LIST DESCRIPTION DESCRIPTION Handle Socket Lock Washer Big Pump Core R-clip U-Limit Ring Small Pump Core Clevis Pin... -
Page 17: Pump Parts Diagram
PUMP PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 18: Ram Parts Diagram
RAM PARTS DIAGRAM DESCRIPTION DESCRIPTION Cylinder Nylon Ring O-Ring Screw PTFE Washer Spring Nylon Block Screw Screw Piston Rod Spring Copper Washer Ball Screw Valve Core Screw Piston Cap O-Ring O-Ring Base Nut PTFE Washer O-Ring Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 19: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
