Front Panel Menu Operation
Device/Circuit Bypass
Use this option if you want to bypass or unbypass a device or circuit from the panel. Usually this is
done when you need to add, remove, repair, or investigate a device or circuit.
To unbypass the device or circuit, follow the same procedure for device/circuit bypass.
Step 1: Select Device/Circuit
- Bypass Menu
-
1 Device /
Circuit
Step 2: Enter your passcode
Enter
passcode for
level 1 or
higher:
Step 3: Select a device
- Select Device
-
Loop: 0
Device: 0 0 0
Step 4: Bypass the device/circuit
Strobe Output
Floor 2
L0 000 not
bypassed.
At this point the display will vary, depending on your choice:
• If you selected "yes", the system will display the message "Device/Circuit bypassed
(unbypassed), then it will return to the Bypass Menu.
• If you selected "no", the system will display the message "Operation cancelled", then it will
return to the Bypass Menu.
19
Press ENTER ( ) when the cursor is flashing
beside "Device/Circuit" to select a device.
Enter your passcode. See page 26 for instructions on
entering passcodes.
1. Use and
number.
2. Enter the loop number, then press ENTER (
3. Enter the device number, pressing
as needed to move left and right.
4. Press ENTER (
1. The systems now asks you whether or not you would
like to bypass or unbypass the device. Use
to select "yes" or "no".
2. Press ENTER (
to select the loop and device
and
) to continue.
) to continue.
).
and
