Compass Model Sport X Assembly Manual page 27

Part No. Part Description
02-0233 Counter gear shaft
02-0803 Cross members 3x30
02-0805 Cross members M3x30
02-0807 Cross members M3x60
02-0819 Struts
02-0820 Skid end cap
02-0821 Skids
02-0833 Front servo mount
02-0834 Front servo tray
02-0837 Main frame right
02-0838 Main frame left
02-0839N Canopy standoff front
02-0840N Canopy standoff back
02-1232 Bearing holder plastic (tail drive)
02-1843 Gyro tray plastic
02-3401 Counter gear (machined)
02-3811 Tank rubber dampener
02-5006 Fuel tank assembly
02-5202 Tail drive pulley
60-5134 Ball bearing 5x13x4
60-6103 Ball bearing 6x10x3
60-6196 Ball bearing 6x19x6
60-8196 Ball bearing 8x19x6
80-0308 Cap Head Bolts M3x8
80-0310 Cap Head Screw M3x10
80-0316 Cap Head Bolt M3x16
80-0322 Cap Head Bolt M3x22
80-0335 Cap Head Bolts M3x35
81-0316 Set Screw M3x16
82-3201 washer 3.2x10x1.2
95-0310 Self tapping bolt M3x10
95-0316 Self tapping bolt M3x16
95-0320 Self tapping bolt M3x20
90-0302 Hexagonal nut3x2.5
91-0003 Nylon nut M3
Order No.
02-0233S Counter gear shaft with E-Clip
02-0803 Cross members 3x30
02-0805 Cross members M3x30
02-0807
Cross members M3x60
02-0819 Struts
02-0820 Skid end cap set
02-0821
Skids
02-0833S Front servo mount w, bolts
02-0834 Front servo tray
02-0837
Main frame right
02-0838 Main frame left
02-0840N Canopy standoff set(sport)
02-0840N Canopy standoff set(sport)
02-1232 Bearing holder plastic (tail drive)
02-1843 Gyro tray plastic
02-3401S Counter gear (machined)
02-3811 Tank rubber dampener
02-5006 Fuel tank assembly
02-5202S Tail drive pulley
60-5134
Ball bearing 5x13x4
60-6103 Ball bearing 6x10x3
60-6196 Ball bearing 6x19x6
60-8196
Ball bearing 8x19x6
80-0308 Cap Head Bolts M3x8
80-0310 Cap Head Screw M3x10
80-0316
Cap Head Bolt M3x16
80-0322 Cap Head Bolt M3x22
80-0335 Cap Head Bolts M3x35
81-0316
Set Screw M3x16
82-3201 washer 3.2x10x1.2
95-0310 Self tapping bolt M3x10
95-0316
Self tapping bolt M3x16
95-0320 Self tapping bolt M3x20
90-0302 Hexagonal nut3x2.5
91-0003 Nylon nut M3
Order Description Qty.
2 pcs/bag
3 pcs/bag
5 pcs/bag
3 pcs/bag
2 pcs/bag
4 pcs/bag
2 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
4pcs/bag
4pcs/bag
2 pcs/bag
1 pcs/bag
1 pcs/bag
4 pcs/bag
1 set/bag
1 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
