Compass Model Sport X Assembly Manual page 23

Part No. Part Description
02-0205 Tail Ball link
02-0209 Tail rotor hub
02-0213 Tail slide ring sleeve
02-0214 Tail shaft
02-0220 Tail pitch plate Collar
02-0225 Grooved parallel pin
02-0226 Guide pin bolt
02-0227 Fin Bushing
02-0234 Tail pitch lever collar
02-0250 Tail blade
02-0261 Tail pitch lever
02-0262 Pulley wheel
02-0263 Tail case plastic
02-0264AB Tail blade holder
02-0701 Stainless link balls
02-0709 Ball links
02-0727 Rudder servo mount
02-0818 Tail control rod guide clamp
02-0826 Tail boom 705mm
02-1211 Tail pitch plate w, BB
02-1212 Tail pitch slider
02-7002 Tail assembly set
40-2650S Tail control rod 2X650
60-3092 Ball bearing 3x9x2.5
60-4094 Ball bearing 4x9x4
60-5134 Ball bearing 5x13x4
60-7113 Ball bearing 7x11x3
61-4083 Flanged bearing 4x8x3
63-4094 Thrust Bearing 4x9x4
80-0206S Cap Head Screw M2x6
80-0208 Cap Head Bolt M2x8
80-0208S Cap Head Bolt M2x8
80-0310 Cap head Bolt M3x10
80-0314 Cap head Bolt M3x14
80-0316 Cap Head Bolt M3x16
80-0330 Cap Head Bolt M3x30
80-2508 Cap Head Bolt M2.5x8
81-0305 Set Screw
82-2578 washer 2.7x7x0.8
82-3402 Plain Washer 3.2x5.2x0.3
84-0212 Spring Pin 2x12
90-0302 Hexagonal Nut 3x2.5
91-0003 Nylon nut M3
95-2508 Self Tapping Bolt 2.5x8
95-2516 Self TappingBolt 2.5x16
98-61600 Tail belt S3M1569
Order No.
02-0205S Tail blade links
02-0209
Tail rotor hub
02-0213 Tail slide ring sleeve
02-0214 Tail shaft
Provided w, 02-7002
Provided w, 02-0205S
Provided w, 02-0261Z
02-0227
Fin Bushing
provided w, 02-0261Z
02-0250 Tail blade
02-0261Z
Tail pitch lever set w,BB,collar
02-0262S Tail rotor pulley with spring pin
02-0263Z Tail case plastic w, BB & bolts
02-0264AB Tail blade holder
02-0701 Stainless link balls
02-0709 Ball links
02-0727S Tail boom servo mount set plastic
02-0818S Tail control rod guide clamp
02-0826 Tail boom 705mm
02-1211 Tail pitch plate w, BB
02-1212Z
Tail pitch slider assembly w, BB
02-7002 Tail assembly set
40-2650S Tail control rod 2X650
60-3092
Ball bearing 3x9x2.5
60-4094 Ball bearing 4x9x4
60-5134 Ball bearing 5x13x4
60-7113
Ball bearing 7x11x3
61-4083 Flanged bearing 4x8x3
63-4094 Thrust Bearing 4x9x4
80-0206S
Cap Head Screw M2x6
80-0208 Cap Head Bolt M2x8
80-0208S Cap Head Bolt M2x8
80-0310 Cap head Bolt M3x10
80-0314 Cap head Bolt M3x14
80-0316 Cap Head Bolt M3x16
80-0330 Cap Head Bolt M3x30
80-2508 Cap Head Bolt M2.5x8
81-0305 Set Screw
82-2578 washer 2.7x7x0.8
82-3402
Plain Washer 3.2x5.2x0.3
Provided w, 02-0262S
90-0302 Hexagonal Nut 3x2.5
91-0003
Nylon nut M3
95-2508 Self Tapping Bolt 2.5x8
95-2516 Self TappingBolt 2.5x16
98-61600
Tail belt S3M1569
Order Description
﹠bolts
Qty.
2 pcs/bag
1 pcs/bag
1 pcs/bag
2 pcs/bag
2 pcs/bag
1 set/bag
1 set/bag
1 pcs/bag
1 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
1set/bag
4pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 set/bag
1 set/bag
4 pcs/bag
5 pcs/bag
2 pcs/bag
2 pcs/bag
4 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
1 pcs/bag
