Compass Model Sport X Assembly Manual page 21

Part No. Part Description
02-0110 Spindle washer (3D)
02-0109 Delrin dampener 8mm
02-0111 Rotor hub
02-0113 Spindle shaft 8mm
02-0118 Collar (flybar support)
02-0507 Mixing Arm
02-0532 Bushings
02-1538 Control ball spacer set
02-0539 Flybar collar
02-0540 Flybar control arm
02-0543 Flybar
02-0551 Paddle
02-0554 Flybar weight
02-0701 Stainless link balls
02-1101 Yoke
02-1103 Main blade holder set 8mm
02-1536 Flybar support
60-3083 Ball Bearing 3x8x3
60-4083 Ball Bearing 4x8x3
60-8165 Ball bearing 8x16x5
61-4083 Flanged bearing 4x8x3
63-8165 Thrust bearing 8x16x5
79-0308 Button Head Bolt M3x8
79-0312 Button Head Bolt M3x12
79-0512 Button head bolt M5×12
80-0206S Cap Head Screw M2x6
80-0308 Cap head bolt M 3×8
80-0322S Shanked Bolt M3x22
80-0428 Shanked Bolt M4x28
81-0304 Set Screw
81-0310 Set Screw
81-0404 Set Screw
82-5131 Washer 5.3×13×1
82-821003 Washer 8.2×10×0.3
91-0003 Nylon nut M3
91-0004 Nylon nut M4
95-2516 Self Tapping Screw 2.5x16
97-0920 O - Ring dampener
Order No.
02-0110 Spindle washer (3D)
02-0109 Delrin dampener 8mm
02-1101S
Rotor hub with Yoke
02-0113 Spindle shaft 8mm
02-0118 Collar (flybar support)
02-0507 Mixing arm set
02-0531S Bushing set (includes 3 sizes)
02-1538 Control ball spacer set
02-0539
Flybar collar
02-0540S Flybar control arm w, set screw
02-0543 Flybar
02-0551S Paddle set
02-0554S Flybar weight w, set screw
02-0701 Stainless link balls
02-1101S
Rotor hub with Yoke
02-1103 Main blade holder set 8mm
02-1536S Flybar support
60-3083 Ball bearing 3x8x3
60-4083 Ball bearing 4x8x3
60-8165 Ball bearing 8x16x5
61-4083
Flanged bearing 4x8x3
63-8165 Thrust bearing 8x16x5
79-0308 Button Head Bolt M3x8
79-0312 Button Head Bolt M3x12
79-0512 Button head bolt M5×12
80-0206S Cap Head Screw M2x6
80-0308
Cap head bolt M3×8
80-0322S Shanked Bolt M3x22
80-0428 Shanked Bolt M4x28
81-0304 Set Screw
81-0310 Set Screw
81-0404 Set Screw
82-5131
Washer 5.3×13×1
82-821003 Washer in 8mm main grip
91-0003 Nylon nut M3
91-0004 Nylon nut M4
95-2516 Self Tapping Screw 2.5x16
Z-97-0920 O ring 13×9×2 for 8mm spindle
Order Description Qty.
2 pcs/bag
2 pcs/bag
1 set/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
6 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
10 pcs/bag
1 set/bag
2 pcs/bag
1 pcs/bag
5 pcs/bag
5 pcs/bag
2 pcs/bag
4 pcs/bag
2 set/bag
10 pcs/bag
10 pcs/bag
10pcs/bag
10 pcs/bag
10pcs/bag
2 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
4 pcs/bag
