Equipment illustration
Receiver
Battery
Please check first your radio manuals before connecting these electronic devices as shown below.
Receiver
Battery
9
Phasing Control Ring Adjustment
Main Grip
Phasing Control
Ring
Elevator Servo
Pitch Servo
Washout Arm
Throttle
Aileron
Elevator
Throttle
Gyro Gain
Gyro
Rudder
Pitch
Main Grip
Boom
To get the right phasing adjustment,
turn the Phasing Control Ring until
the Washout Arms and Main Grips
are parallel to the Tail Boom.
Boom
0
10
Gyro
Rudder Servo
Aileron Servo
JR
Hitec/Futaba
Ch1
Ch2
Ch2
Ch3
Ch3
Ch1
Aux2
Ch5
Ch4
Ch4
Aux1
Ch6
0
10
Washout Arm
Phasing Control Ring
20
30
40
20
30
40
Parallel to
the Boom
