Compass Model Sport X Assembly Manual page 25

Part No. Part Description
02-0301 Cooling fan hub
02-0304 Cooling fan
02-0307 Starter coupling
02-0310 Engine mount (sport)
02-0312 Clutch Liner
02-0317 Start Shaft
02-0321 Clutch bell
02-0323 Clutch
02-0504 Washout base block
02-0518 Washout links
02-0532 Bushings
02-0535 Wash control arm
02-0603 Main shaft(sport)
02-0604 Cover
02-0607 Mast lock
02-0615 Auto-rotation shell
02-0617 Autorotation sleeve
02-0701 Stainless link balls
02-1519 Slide block
02-3302 Drive gear
02-4503 Second gear molded
02-4602 Main gear molded
02-5014 Double gear assembly
02-5402 Swash plate
60-10195 Ball bearing 10x19x5
60-4083 Ball bearing 4x8x3
60-6124 Ball bearing 6x12x4
60-6196 Ball bearing 6x19x6
60-8196 Ball bearing 8x19x6
61-2562 Flanged bearing 2.5x6x2.6
62-0612 One way bearing 6x10x12
62-142016 One way bearing 14x20x16
79-0306 Button head Bolt M3x6
80-0206S Cap Head Bolt M2x6
80-0312 Cap Head Bolt M3x12
80-0316 Cap Head Bolt M3x16
80-0327 Shanked Bolt M3x27
80-2505 Cap Head Bolt M2.5x5
80-2520 Cap Head Bolt M2.5x20
81-0404 Set Screw
81-0406 Set Screw
82-3201 Washer
91-0003 Nylon nut M3
Order No.
02-0301 Cooling fan hub
02-0304 Cooling fan
02-0307S Starter coupling
02-0310 Engine mount (sport)
02-0312 Clutch liner
02-0317S Starter shaft w, E-Clip
02-0321Z Clutch bell w, BB and liner
02-0323Z
Clutch w, one way bearing and bolts
02-0504S Washout base set (w, 2 bases)
02-0518 Washout links
02-0531S
Bushing set (includes 3 sizes)
02-0535 Wash out control arm
02-0603 Main shaft(sport)
provided with 02-5014
02-0607S Mast lock collar w, screw
02-0615Z Autorotation hub with one way bearing
02-0617S Autorotation sleeve with E-Clip
02-0701 Stainless link balls
02-0504S Washout base set (w, 2 bases)
02-3302 Drive gear
02-4503 Second gear molded
02-4602 Main gear molded
02-5014 Double gear assembly
02-5402 Swashplate
60-10195 Ball bearing 10x19x5
60-4083 Ball bearing 4x8x3
60-6124
Ball bearing 6x12x4
60-6196 Ball bearing 6x19x6
60-8196 Ball bearing 8x19x6
61-2562
Flanged bearing 2.5x6x2.6
62-0612 One way bearing 6x10x12
62-142016 One way bearing 14x20x16
79-0306
Button head Bolt M3x6
80-0206S Cap Head Bolt M2x6
80-0312 Cap Head Bolt M3x12
80-0316
Cap Head Bolt M3x16
80-0327 Shanked Bolt M3x27
80-2505 Cap Head Bolt M2.5x5
80-2520 Cap Head Bolt M2.5x20
81-0404 Set Screw
81-0406 Set Screw
82-3201 Washer
91-0003 Nylon nut M3
Order Description Qty.
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 set/bag
1 pcs/bag
1 set/bag
2 pcs/bag
6 pcs/bag
2 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
10 pcs/bag
1 set/bag
1 pcs/bag
1 pcs/bag
1 pcs/bag
1 set/bag
1 set/bag
4 pcs/bag
5 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
4 pcs/bag
1 pcs/bag
1 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
