M o d u l e S p e c i f i c a t i o n s

Mechanical

Digi Connect Digi Connect
Dimensions
ME Wi-ME
1.445 in. 1.945 in
Length
(36.703 mm) (49.4 mm)
0.75 in.
Width
(19.05 mm)
0.735 in.
Height
(18.669 mm)
Device/serial 20-pin micro header (10-pin double row) with .50-inch (1.27-mm)
pitch (Samtec P/N FTS-110-01-F-DV-TR or similar). Positions 3
interface
through 6 are removed.
connector
