Ethernet Interface Pin Orientation
Pin
1
TXD+
Transmit
Data +
1 4
D i g i C o n n e c t W i - M E & D i g i C o n n e c t M E H a r d w a r e R e f e r e n c e
Pin 8
Pin 1
Ethernet Interface Pin Assignments
Pin Pin Pin
2 3 4
TXD- RXD+ EPWR+
Transmit Receive Power
Data - Data + from
Switch +
Pin Pin
5 6
EPWR+ RXD- EPWR-
Power Receive Power from
from Data - Switch -
Switch +
Pin Pin
7 8
EPWR-
Power from
Switch -
