GPIO Port Pin Orientation
Pin
Pin
1
Signal
GND
GPIO-5

Connectors and Blocks

The development board provides the following connectors and blocks:
See the figure titled "Board Layout" on page 18 for the location of the connectors and
blocks. The following sections describe the connectors and blocks.
Embedded Module Connector, P7
The Digi Connect ME embedded module Connector is a 20-pin female vertical header that
is labeled P7 on the development board. The connector is used with the integration kit and
GPIO Port Pin Assignments
Pin
Pin
2
3
4
GND
GPIO-4
Embedded Module Connector, P7
Module JTAG Interface Connector, P8
JTAG Debugger Connector, P4
Jumper Block, P12
Logic Analyzer Header, P6
A b o u t t h e D e v e l o p m e n t B o a r d
Pin 1
Pin 10
Pin
Pin
Pin
5
6
7
GND
GPIO-3
GND
Pin
Pin
Pin
8
9
10
GPIO-2
GND
GPIO-1
2 3
