& Enclosure For Sentinel Kinetic Advance S & SX Fitting Instructions Stock Ref. No: TOP BOX 478075 - Advance S & SX ENCLOSURE 478080 - Advance S 478081 - Advance SX READ IN CONJUNCTION WITH ILLUSTRATIONS PLEASE SAVE THESE INSTRUCTIONS...
Page 2
These instructions should be read in conjunction with the Sentinel Kinetic Advance MVHR Installation and Commissioning Manual (Vent-Axia part no. 474957). Important: Check spigot configuration for LEFT or RIGHT HAND setup “These units are heavy and should only mounted on walls capable of bearing their weight i.e.
Option A Acoustic Top Box + MVHR unit SIZE & WEIGHT WEIGHT Top Box without unit 14kg Top Box with unit 41kg Advance Unit 27kg...
Page 4
FIX MOUNTING BRACKETS Use Acoustic Bracket Kit 1 (478818) to mount Unit & Top Box. Bracket to be mounted to 502mm centres. MOUNTING UNIT TO BRACKETS Once brackets are mounted, unit can be attached to hanging brackets (see view A) with the clips on the rear of the unit.
Page 5
MOUNTING TOP BOX TO BRACKETS 1. Before mounting the Top Box, the front cover will need removed before install.
Page 6
2. Use 4-off M5x16 screws supplied in Bracket kit 1, fix the screw in half way on the mount brackets. 3. Then lift Top Box over the spigots and then line up the 4 screws with the key-hole slots on the rear of the Top Box (see view B).
Page 7
SPIGOT ATTACHMENT ON TOP BOX Connect all spigots to the unit, then use duct tape to seal & secure them in place. Two foam pieces supplied with Top Box are to be used on “To Atmosphere” & “From Atmosphere” spigots, wrap each foam piece around base of spigots (see view C).
Page 8
Image shows a Right Hand setup with foam insulation fitted on “To Atmosphere” & “From Atmosphere” spigots. FITTING FRONT COVER TOP BOX Once unit is installed and commissioned, as per Installation & Commissioning instructions, then secure front panel back onto Enclosure.
Page 9
Option B Acoustic Enclosure + MVHR unit SIZE & WEIGHT WEIGHT Enclosure without unit 31kg with unit 54kg Enclosure Advance Unit 27kg...
Page 10
FIX MOUNTING BRACKETS Unpack mounting brackets from separate box and assemble and fix in accordance with the Instruction leaflet supplied with the brackets to 560mm centres. IMPORTANT 200mm minimum clearance must be left under the mounting brackets to allow access, for tightening the mounting bolts.
ENCLOSURE PARTS ENCLOSURE PARTS ITEM QTY DESCRIPTION BASE PANEL SIDE PANEL TOP PANEL FRONT PANEL – Advance S FRONT PANEL – Advance SX REAR PANEL AV MOUNT NUT M8 SPRING WASHER M8 WASHER M6 SCREW M6 X 16 SCREW NO6x1/2IN POZI PAN RUBBER GROMMET...
Page 13
BACK PANEL & UNIT MOUNT IMPORTANT – ASSISTANCE WILL NEEDED AT THIS STAGE. 1. First fix the 4 anti-vibration washers (ONLY) to the mounting brackets. (Supplied in bracket kit) 2. Then place the back panel onto the mounting brackets, grommet ends to the bottom. 3.
Page 14
FIT TOP AND SIDE PANELS FIT BACK PANEL Once back panel is fitted, push unit back towards the brackets and tighten the 4 bolts on the mounting brackets. IMPORTANT 200mm minimum clearance must be left under the mounting brackets to allow access, for tightening the mounting bolts.
Page 15
MOUNT UNIT ON BRACKETS Mount unit on brackets in accordance with instruction leaflet supplied with brackets FIT FRONT PANEL Once unit is installed and commissioned, as per Installation & Commissioning instructions, then secure front panel back onto Enclosure. Note: Once front cover is fitted, all alerts and warnings are on the wired remote control display.
Page 16
Option C Acoustic Enclosure & Top + MVHR unit SIZE & WEIGHT WEIGHT Top Box without unit 14kg Enclosure without unit 31kg Enclosure & Top Box with unit 70kg Advance Unit 27kg...
Page 17
FULL SOLUTION BUILD 1. Start with instructions - “Option B” Enclosure only – Pages 9 – 15. 2. Then remove the front panel of the Top Box, then place it on top of the Enclosure - “Option A” Top Box only – Pages 5. 3.
FLOOR MOUNTING For floor mounting a suitable cradle should be made to accommodate the condensate outlet and trap. Installer to ensure consideration of the condensate outlet and trap on bottom of unit. Installer Notes: __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________...
Page 20
Vent-Axia guarantees its products for two years from date of purchase against faulty material or workmanship. In the event of any part being found to be defective, the product will be repaired, or at the Company’s option replaced, without charge, provided that the product:- Has been installed and used in accordance with the instructions given with each unit.
