LuminAir
Fan & Light
Ventilation Kit
Fitting and wiring instructions
Supply voltage to transformer/controller 220-240V/1/50Hz
Output to fan 12V SELV/1/50Hz
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
Stock Ref. No
LuminAir Kit L
453410A
LuminAir Kit T
453413A
LuminAir Kit H
453416A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LuminAir Kit L and is the answer not in the manual?

Questions and answers

Summary of Contents for Vent-Axia LuminAir Kit L

  • Page 1 LuminAir Fan & Light Ventilation Kit Fitting and wiring instructions Stock Ref. No LuminAir Kit L 453410A LuminAir Kit T 453413A LuminAir Kit H 453416A Supply voltage to transformer/controller 220-240V/1/50Hz Output to fan 12V SELV/1/50Hz PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
  • Page 3 ONLY CONNECT TOGETHER THE PRODUCTS SUPPLIED FROM LUMINAIR RANGE AS THE FAN IS SPECIALLY DESIGNED TO OPERATE AT 12V AC AND IS NOT COMPATIBLE WITH OTHER VENT-AXIA CONTROLLERS. DO NOT CONNECT MORE THAN ONE FAN UNIT TO THE FAN CONTROLLER.
  • Page 4 3. SITING THE LUMINAIR 3.1 The electrical supply to the LuminAir fan is 12V AC SELV from the mains transformer controller and the Luminair light is 12V DC from the mains lighting LED driver. This allows the LuminAir fan & light to be installed within reach of a person using a fixed bath or shower ie.
  • Page 5 CONTROLLER FROM MAINS SUPPLY The Vent-Axia LuminAir is specially designed for use with the supplied 12VDC LED lamp rated at 3W. The lamp is a straight push in/pull out type. Any twisting movement, when removing/replacing the lamp, should be avoided.
  • Page 6 Fig 2. LuminAir Kit T (Ref. No 453413A) 12VDC 12V ~ 50Hz Fig 3. LuminAir Kit H (Ref. No 453416A) 12VDC 12V ~ 50Hz...
  • Page 8 Applicable only to products installed and used in the United Kingdom. For details of guarantee outside the United Kingdom contact your local supplier. Vent-Axia guarantees its products for two years from date of purchase against faulty material or workmanship. In the event of any part being found to be defective, the product will be repaired, or at the Company’s option replaced, without charge, provided that the product:-...
