Silhouette
Installation and Wiring Instructions
220-240V~50Hz
PLEASE READ INSTRUCTIONS IN CONJUNCTION WITH ILLUSTRATIONS.
PLEASE SAVE THESE INSTRUCTIONS.
Stock Ref. N°
45 40 55B (100B)
44 51 61
(125B)
45 40 59B (150X)
45 40 56B (100T)
44 51 62
(125T)
45 40 60B (150XT)
45 40 57B (100HT)
44 51 63
(125HT)
45 40 61B (150XHT)
45 40 58B (100TM)
IPX4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Silhouette 45 40 55B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vent-Axia Silhouette 45 40 55B

  • Page 1 Silhouette Installation and Wiring Instructions Stock Ref. N° 45 40 55B (100B) 44 51 61 (125B) 45 40 59B (150X) 45 40 56B (100T) 44 51 62 (125T) 45 40 60B (150XT) 45 40 57B (100HT) 44 51 63 (125HT) 45 40 61B (150XHT) 45 40 58B (100TM) 220-240V~50Hz...
  • Page 2: Safety And Guidance Notes

    C. Ensure that the mains supply (Voltage, Frequency, and Phase) complies with the rating label. D. The Fan should only be used in conjunction with the appropriate Vent-Axia products. E. The fan should only be used in conjunction with fixed wiring.
  • Page 3: Installation

    A. INSTALLATION IMPORTANT: The fan should only be used in conjunction with fixed wiring. PANEL/CEILING MOUNTING For panel/ceiling mounting the fan should be installed into a closed duct system of at least 1.2m long or protected by an exterior air grille that must comply with the standard requirements of your country to prevent access to the fans impeller.
  • Page 4: Timer Adjustment

    C. SETUP WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY DURING THE INSTALLATION / OR MAINTENANCE. NOTE On all 150mm fans the shutter may take up to one minute to activate on start-up, and the same amount of time to close when the fan is switched off.
  • Page 5: Servicing And Maintenance

    SILHOUETTE 100TM Single speed with PIR (passive infra-red) detector and overrun timer. The fan starts automatically when a movement is detected and will continue to operate for the set overrun time period. (See ‘Timer Adjustment’ section above) Fig. 2 and 5. D.
  • Page 6 Fig.4 Fig.5. Fig.6. To activate the timer function remove jumper JP1. Once removed the fan will run on for a fixed time period of approx. 15 mins. Humidity Timer Adjustment Adjustment To REDUCE the operating time, use a small To LOWER the set-point use a small screwdriver to screwdriver to turn the adjuster ANTI-CLOCKWISE.
  • Page 8: The Vent-Axia Guarantee

    Vent-Axia guarantees its products for two years from date of purchase against faulty material or workmanship. In the event of any part being found to be defective, the product will be repaired, or at the Company’s option replaced, without charge, provided that the product:- ...
