- Page 1 S V A R A S t y l i s h a n d ve rs at i l e ba t h roo m f a n A product by Instruction Manual...
- Page 2 Frequency, and Phase) complies with the rating label. moving parts. If the external grille is positioned between 0-2.3m from the ground, please use the Vent-Axia wall D. The Fan should only be used in conjunction with the kit to ensure people cannot access the fans impeller appropriate Vent-Axia products.
-
Page 3: Installation Preparation
Installer information Installation • Fit the enclosed wall Installation Preparation gasket as shown in • Loosen the motor unit by grasping it as shown in Figure the figure (C_1). (A), prise off the motor unit by leveraging against the cap with your knuckles. - Page 4 Installer information • Vent-Axia wall kits and external grilles are available as • Use ageing-resistant sealant accessories. (Figure E). to seal around cables that are laid through the wall seal. The fan’s wall seal has a short spigot which fits inside the Ø100 mm pipe.
- Page 5 Installer information • Mark the three attachment points for the appropriate screws to the substrate (Figure J). Tighten the screws so that gasket seals against the wall. 100-240 V AC connection Always use a qualified electrician All electrical connections 100-240V must be performed by a qualified electrician.
- Page 6 (Can be combined with backdraught shutter) 100-240VAC 50 / 60Hz Must be selected via Vent-Axia Connect App. Start / stop via manual switch T. (start = max. RPM, stop = 15 minutes run-on time)
- Page 7 (Figure O.) simultaneously (Figure N). ELECTRICAL CONNECTION 12VDC NOTE! 12VDC voltage must not exceed NOTE. Vent-Axia recommends that electrical connection of between 10 - 13,6VDC. 12 VDC be performed by a qualified electrician. Svara auto: 12VDC (switch C always on) Continuous trickle ventilation, automatic boost at elevated humidity levels, and via the integrated light sensor.
- Page 8 Installer information Mounting the cover on the wall frame • The fan is double insulated and must not be earthed. When the electrical connection is made place the cover back over the wall frame fitted into the housing hole (Figure P). •...
-
Page 9: Default Setting
Automatic functions and settings via app Default setting: Activate the app: Vent-Axia Svara is programmed to cope with the vast You have to use a code to activate the app, the code is majority of installations. unique for each fan. Enter the code or scan it through your The fan works continuously at a trickle flow of 10l/s. -
Page 10: Servicing And Maintenance
For the user Servicing and maintenance WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY DURING MAINTENANCE. Strong solvents should not be used on the fan. – Clean opening, the duct and the motor unit with a damp The fan must not be dipped in or sprayed with water. -
Page 11: The Vent-Axia Guarantee
Supplier guarantees the functioning of the relevant supplier. regulations and instructions are complied with. Vent-Axia guarantees its Lo-Carbon products for five All the holes for the screws to be carried out according to years from date of purchase against faulty material or the figures X and Y. - Page 12 Ø140-160 Stock Ref. 409820 Cover Plate - Black for duct dimensions between Ø140-160 Stock Ref. 497117 EU Authorised Representative: Vent-Axia Bedrijvenweg 17 7442 CX Nijverdal Internal Fit Wall Kit - White Nederland with Backdraught Shutter authorisedrep@vent-axia.nl Stock Ref. 474779...
