1.3. Production Details
Manufacturer:
TE CONNECTIVITY
Berwyn, PA 19312
USA
Machine Title:
CAP-6T Drawer Machine (P/N 1689700-1)
CAPI-6T In-line Conveyor Machine (P/N 1689700-2)
CAPI-6T Shuttle Machine (P/N 1689700-3)
Machine Function
Compliant pin connector press.
Machine Usage
The CAP is an automatic stand-alone unit that presses compliant pin connectors into a printed circuit
board (PCB).
Restriction on Hazardous Substances (RoHS)
Information on the presence and location of any substances subject to RoHS (Restriction on Hazardous
Substances) can be found at the following website:
http://www.te.com/usa-en/utilities/product-compliance.html
Click on Find Compliance Status and enter equipment part number.
1.4. General Specifications
Dimensions
●Length: 1910 mm [75 in.] (without monitor attachment)
●Width: 1525 mm [60 in.] (including door handles)
●Height: 1780-1830 mm [70-72 in.] (Adjustable feet to allow setting the conveyor height to SMEMA
specification.)
Weight
Approx. 1814 kg [4,000 lbs] (shipping weight 2042 kg [4,500 lbs])
Atmosphere
Ambient Operating Temperature range: 5 to 40°C [41 to 104°F].
Altitude: Up to 1000 m [3300 ft] above sea level.
Relative Humidity range: 20 to 95% (non-condensing).
Transportation and Storage: -25 to 55°C [-13 to 131°F] and up to 65°C [149°F] for short periods not
exceeding 4 hours. Suitable means shall be provided to prevent damage from excessive moisture,
vibration, stress, and mechanical shock during shipment.
Electrical power: (recommended) 208-230VAC, 25 Amp, 50/60 Hz, 1-phase (full range: 200-240VAC).
Pneumatic:.55 to .83 MPa [80 PSI to 120 PSI].
Not for operation within an explosive atmosphere.
1.5. Capabilities
The CAP delivers a controlled force of up to 6 tons 53.4 Kn [12,000 lbs]. Up to (12) connector pressing tools
(top tools) and (1) calibration tool are stored in an integrated tool rack. They are automatically loaded into the
exclusive "floating head" as needed. Lead-in on the pressing tool and connector guides the floating head up to
0.4 mm [.015 in.] in any direction to correct for inaccuracies in connector position, as the tool is inserted into the
connector. Force transducers detect the force and can stop the process immediately before damage is done to
the connector or board.
For the CAP-6T, the PCB size limit is 762 mm [30 in.] x 914 mm [36 in.].
Rev A
409-32048
6 of 64
