Operating Instructions
HT11K hand tool TH 0.25 terminals,
PN: 7-1579014-1 / 7-1579014-2 / 7-1579014-3
Operating Instructions no.:
Operating Instructions PN:
Language:
411-18591-1 Rev. A2
2-744017-4
en (Translation)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT11K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TE Connectivity HT11K

Summary of Contents for TE Connectivity HT11K

  • Page 1 Operating Instructions HT11K hand tool TH 0.25 terminals, PN: 7-1579014-1 / 7-1579014-2 / 7-1579014-3 Operating Instructions no.: 411-18591-1 Rev. A2 Operating Instructions PN: 2-744017-4 Language: en (Translation)
  • Page 2 It should be noted that our products are subject to natural wear and ageing pro- cesses. © All rights reserved by TE Connectivity Ltd., including applications for industrial property rights. We reserve all rights of disposal such as copying and transfer rights.

  • Page 3: Table Of Contents

    General specifications ....................3 Copyrights, industrial property rights ..................3 Using these operating instructions ................3 Abbreviations used ....................... 4 General Safety Instructions ..................4 Intended use ......................... 4 Improper use ......................... 5 Reasonably foreseeable misuse ..................5 Warnings in these instructions ....................5 3.4.1 General information ......................

  • Page 4: General Specifications

    The copyright to these operating instructions is held by TE Connectivity Ltd. These operating instructions are only intended for users of the HT11K TH 0.25 terminals tool, TE PN 7- 1579014-1 / 7-1579014-2 / 7-1579014-3 (hereinafter referred to as the "hand tool").

  • Page 5: Abbreviations Used

    2.1 Abbreviations used Abbreviation Meaning Part number RoHS Restriction of (the use of certain) hazardous substances 3 General Safety Instructions The hand tool has been manufactured in accordance with the generally accepted codes of practice. Nonetheless, there is a risk of personal injury and material damage if the following general safety in- structions and the warnings preceding the individul operating instructions are not followed.

  • Page 6: Improper Use

    Notification regarding use: Cumulative trauma complaints may result from prolonged use of hand tools. TE Connectivity hand tools are intended for occasional use with low part counts. TE Connectivity offers a wide selection of tools to meet increased demand or for production.

  • Page 7: While Working With The Hand Tool

    Dispose of the tool in compliance with the environmental rules described in Section 9 "Disposal". 3.5 User obligations The user of the hand tool from TE Connectivity Ltd. must train their personnel on the following mat- ters: Following and using the operating instructions and observing statutory provisions.

  • Page 8: Scope Of Delivery

    4 Scope of delivery The scope of delivery comprises the following: 1 hand tool TE PN 7-1579014-1, 7-1579014-2 or 7-1579014-3 1 Operating instructions 411-18591 / TE PN 2-744017-4 5 Terminals to be processed The following TH 0.25 system terminals are processed using the hand tool: TE - Cross- Terminal...

  • Page 9: Hand Tool Description

    6 Hand tool description The HT11K hand tool essentially consists of a crimping head and a moveable grip joined by rivets. The grip has a ratchet mechanism to ensure proper crimping in accordance with TE specifications. The crimping head is equipped with a sliding crimping die designed to match the product to be pro- cessed.

  • Page 10: Crimping Procedure

    7 Crimping procedure Based on the wire cross-section and the relevant processing specification, determine the right crimp- ing die for the terminal to be processed. Proceed as follows to crimp the terminal: Close the handles until the ratchet releases and allows you to fully open the handles. Note: The ratchet mechanism makes audible clicks when you close the handles.
  • Page 11 Figure 4: Fold out the terminal positioner Figure 5: Inserting a terminal with the terminal positioner open Next, press the terminal positioner down so the terminal can be inserted in the terminal holder. Insert the terminal into the terminal holder until it reaches the stop with the terminal positioner open.
  • Page 12 Fig. 6: Wire inserted up to terminal positioner Fig. 7: Close the hand tool Insert the wire and sealing ring into the terminal. Hold the wire against the stop (terminal position- er). Squeeze the hand tool completely closed. Note: The hand tool opens automatically after it is completely closed; otherwise it remains closed. Operating Instructions 12/14 2-744017-4...
  • Page 13 If the terminal is stuck, wiggle it slightly to remove it. Check the crimp height of the crimped terminal. Based on the information in the TE Connectivity processing specification and the drawing (see Section 5).

  • Page 14: Maintenance And Servicing

    In case of disposal, please send the hand tool and its components back to the address specified in section 10.1 Contact Information. 10 Customer support address TE Connectivity c/o Schenck Technologie- und Industriepark GmbH Landwehrstrasse 55, Building 83 64293 Darmstadt Field Service EMEA@te.com...

This manual is also suitable for:

7-1579014-17-1579014-27-1579014-3
