Figure 2-12. RS232 to USB Converter "Y" Cable +12V (PC Enumerates this device as an RS-232 COM port)
2.4 Operation
The CyberData 4-Port PoweredUSB 2.0 Hub is a standard USB Hub that complies with the USB 2.0
specification, and adds PoweredUSB ports. When connected to a Host, it is enumerated as a
Generic USB Hub. This Hub also meets the PoweredUSB .08g specification. For more information
about this specification, go to www.poweredusb.org.
Operations Guide
Figure 2-13. Cable, +24V PoweredUSB to 1x8 PoweredUSB
Figure 2-14. RS232 to USB Converter "Y" Cable +24V
930105E
Installing and Using the 4-Port PoweredUSB Hub
CyberData Corporation
13
Operation
