5. Starting Web Management
The following shows how to start up the Web Management of the
Industrial L2+ Managed Switch. Note the Industrial L2+ Managed
Switch is configured through an Ethernet connection. Please make sure
the manager PC must be set to the same IP subnet address.
For example, the default IP address of the Industrial L2+ Managed
Switch is 192.168.0.100, then the manager PC should be set to
192.168.0.x (where x is a number between 1 and 254, except 100),
and the default subnet mask is 255.255.255.0.
IGS Industrial Switch
RJ45/UTP-Cable
IP Address:
192.168.0.x
IP Address:
192.168.0.100
Figure 5-1: IP Management Diagram
12
