4.1 Logging on to the Console

Once the terminal has been connected to the device, power on the
Industrial L2+ Managed Switch and the terminal will display "running
testing procedures".
1. There are three switches (IGS-10080MFT/IGS-12040MT/
IGS-20040MT) with the RJ45 type console interface.
2. The following console screen is based on the IGS-
10020HPT; the display of the IGS-10020HPT is the
Note
same as that of the IGS-10080MFT/IGS-12040MT/
IGS-20040MT.
Then, the following message asks to log in user name and password
as shown in Figure 4-3. Please enter the factory default user name
"admin" and password "admin".
User name: admin
Password: admin
1. For security reason, please change and memorize
the new password after this first setup.
2. Only accept command in lowercase letter under
Note
console interface.
Figure 4-3: Console Login Screen
