Page 1
Quick Installation Guide IPM-4220/IPM-8220 IP-based 4-/8-port Switched Power Manager 1. Package Contents Thank you for choosing PLANET IP-based Switched Power Manager. The Switched IPM provides the useful function of managing power for any combination to connect with itself. Open the box of the Switched IPM and carefully unpack it. The box should contain the following items: ...
Please avoid any items or liquids entering the device because their contact with dangerous voltage points or short-circuit parts may cause a fire or electric shock. 3 Physical Introduction Rear Panel : IPM-4220 Front Panel : System Indicating Light Slow flashing: Normal operating Rapid flashing: Normal updating...
COM2/1 2 Com Ports provided to enable terminal control, API control and 2 mutual cascading Circuit Breaker Protection Power Inlet Power On/Off Switch Power Outlet Note: The maximum output current is 16 amps. LCD Panel To display total current, voltage and IP Switch/Set button Provide LCD panel in order to switch the total current and IP;...
Page 4
IP Display ■ IP indicating light remaining lit. ■ IP indicating light remaining lit. ■ IP indicating light remaining lit. LCD menu shows the total current. è Hold the Switch/Set button for 3 seconds with a long beep to enter alarm current setting. è Press the Switch/Set button to increase the alarm current by 0.5A in each press.
Page 5
Reset Button RJ45 Ethernet Port USB Connected Port (Future Feature) COM2/1 2 Com Ports provided to enable terminal control, API control and 2 mutual cascading Circuit Breaker Protection Power Inlet Power Outlet Note: The maximum output current is 16 amps. LCD Panel To display total current, branch 1, branch 2, voltage and IP Switch Button...
Page 6
Branch 1 Max. Current Branch 1 Current LCD menu shows total current, and current values of branch 1 and branch 2. è Hold the Set button for 3 seconds with a long beep to enter alarm current setting. è Enter flash mode (LCD will flash after entering setting mode, "S"...
Page 7
Press the Set button to show "maximal power outlet current record", è Hold the Set button for 3 seconds with a long beep to adjust to a zero point. Hold the Switch button for 3 seconds with a long beep in Port ...
Step 3: Enter the IP address and login to the homepage of Switched IPM. 5. Further Information The above steps introduce the simple installation of the Switched IPM. For further details on the installation of the Switched IP Power Manager, please refer to the user manual which you can be downloaded from the PLANET website.
