Appendix B Reference

Appendix B.1. Specifications

Electrical Connections
Power Requirements
Approvals
Power Requirements
Physical Dimensions
Weight
Operating Temperature
Humidity
"This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
•
This device may not cause harmful interference
•
This device must accept any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his expense.
Modifications not expressly approved by Sierra Monitor could void the user's authority to operate the
equipment under FCC rules".
2
Specifications subject to change without notice.
FS-EZ3-MOD-BAC & FS-EZ4-MOD-BAC
One 3-pin Phoenix connector with: RS-485/RS-232 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: RS-485 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: Power port (+ / - / Frame-gnd)
One Ethernet 10/100 BaseT port
Input Voltage: 12-24VDC or 24VAC
Max Power: 3 Watts
CE and FCC Class B & C Part 15, UL 60950, WEEE compliant,
IC Canada, RoHS compliant
12-24VDC or 24VAC
4 x 1.1 x 2.7 in (10.16 x 2.8 x 6.8 cm)
0.4 lbs (0.2 Kg)
-20°C to 70°C (-4°F to158°F)
10-95% RH non-condensing

Figure 50: Specifications

Page 46 of 49
EZ Gateway Modbus to BACnet Start-up Guide
Current draw: 24VAC 125mA
12-24VDC 250mA @12VDC
