5.2

Using Web Configurator GUI

•
Open a web browser and connect to the EZ Gateway's default IP Address. The default IP
Address of the FieldServer is 192.168.2.101, Subnet Mask is 255.255.255.0.
•
If the PC and the EZ Gateway are on different IP networks, assign a static IP Address to the PC
on the 192.168.2.X network.

5.2.1 Controls, Status and Log Functions

Along the right side of every Web Configurator GUI page is a column of buttons and event generated
messages.
•
Controls Panel – Contains the following four buttons:
Reload – Resets all settings to the last saved configuration
o
Defaults – Resets all settings to the default configuration
o
Save – Records all settings
o
Restart – Reboots the Gateway
o
•
Status Information – Shows Gateway messages such as whether the Gateway is online,
element validation status, unsaved settings, etc.
•
Log Messages – Lists last five events and when they were performed.

5.2.2 Accessing SMC Cloud

The FieldPoP™ tab
Monitor's device cloud solution for IIoT. The SMC Cloud enables secure remote connection to field
devices through a FieldServer and its local applications for configuration, management, maintenance. For
more information about the SMC Cloud, refer to the
EZ Gateway Modbus to BACnet Start-up Guide

Figure 9: EZ Gateway Landing Page

(see
Figure 9) allows users to connect to the SMC Cloud, Sierra
SMC Cloud Start-up
Page 14 of 49
Guide.
