ECP200 EXPERT
CHAPTER 1: INTRODUCTION
1.1
DESCRIPTION:
The ECP200 EXPERT is a new control panel for cold rooms with a single-phase
compressor up to 2 HP, specially designed to provide the user with safety, protection,
control and ease of installation.
It allows the user to control all the components on a refrigerating system: compressor,
evaporator fans, defrosting elements, room light and thermostat-holder demisting element.
APPLICATIONS:
- Complete management of single-phase static or ventilated refrigeration systems up
to 2 HP, with off-cycle or electrical defrosting and with direct or pump-down
compressor stop.
- Control of single-phase evaporator unit only with freon solenoid consensus or
remote condensing unit consensus.
MAIN CHARACTERISTICS:
- Direct control of defrosting elements, evaporator fans, room light with outputs
directly connectable to the various units.
- Magneto-thermal cut-out switch for isolation and protection of the refrigeration unit.
- Innovative, smartly designed ABS cover with transparent cover for access to the
magneto-thermal cut-out switch, all with an IP65 protection rating so that panel can
be used outside the room.
LED indicators and large display illustrate system status.
-
User-friendly keypad.
-
Auxiliary relay with parameter-configured activation (alarms, temperature set point,
-
direct control via front push-button, thermostat-holder demisting element, remote
condensing unit consensus, freon solenoid control in the event of compressor
pump-down operation).
- Possibility, as an alternative to an auxiliary relay, of a RS485 port for connection to
the TeleWIN supervision network (industrial TeleNET for local networks without
instrument limits).
- Temperature control to 0.1 °C.
1.2
ECP200 EXPERT
USE AND MAINTENANCE MANUAL
Pag. 4

GENERAL

PRODUCT ID CODES
controls and manages compressor,
defrosting elements, evaporator fans and
room light. Aux/Alarms relay
CHAP. 1 - Introduction
Rev. 04-06
