10.3 Spare parts list

Emergency spare parts
12000201 Belt 25 x 1.6 - Bande 25 x 1.6
12002015 Chain cover - Cache chaîne
12002019 Driving shaft - Arbre moteur
12002020 Driving sprocket - Pignon moteur
12002026 Cap -Flasque
12002027 Chain tensioner - Tendeur
12002029 Cover - Capot
12002032 Steel pulley 200 -Poulie 200 acier
12002033 Washer - Rondelle
12002035 Seal - Joint d'étanchéité flasque
12002036 Seal - Joint d'étanchéité flasque
12002040 Cap - Flasque
12002041 Cover -Capot
12002042 Chain tensioner - Tendeur
12002204 ASA 25/3 Chain - Chaîne + attache
12003003 Guide pin - Pion guidage
12003201 Spring - Ressort
12034201 Belt 12.5x1.5 - Bande retour 180°
11003201 Spring diam. 0.3 - Ressort diam. 0.3 -
80000004 Glue 40g - Colle 40g

10.4 Wearing parts list for maintenance

12000001 Belt guide -Guide bande
12000002 Cover - Cache
12000201 Belt - Bande 25 x 1.6
12000201A Belt beveling - Biseautage bande
12001002 Idling block 200 moulded - Bloc renvoi 200 moulé
12001004 Idling pulley 200 - Poulie renvoi 200
12001005 Cover - Capot
12002003 Pulley washer - Rondelle poulie
12002015 chain cover - Cache chaine
12002019 Driving shaft - Arbre moteur
12002020 Driving sprocket - Pignon moteur
12002024 Washer - Rondelle
12002025 Driving block 200 moulded- Bloc entraînement 200 moulé
Cap - Flasque
12002026
I02-121 User manual & maintenance guide
of TLM 2000
Version 02
(translation of the original manual)
Page 30 sur 41
