8.3 Spare parts list

11001001
11001201
11002001
11002006
11002008
11002009
11002010
11002011
11002012
11002201
11002202
11003003
11003005
11003201
11003202
11004001
11004002
11004003
11004004
11004005
11004006
11004007
11004008
11004009
11004010
11004011
11004012
11004013
11004014
11005001
11005002
11005003
I02-118 User manual & maintenance guide
of TLM 1000
Belt guide
Belt 12.5 x 1
Piston
Plate
Body
Guide
Tray
Sensor bracket L
Sensor bracket R
Spring
Joint
Pin
Bush diam. 6
Spring
Cover dia 6
Cap
Cam SD 100
Cam SG 100
Support
Support
Plate
Cam support
Rail
Rail
Selector
Selector L
Cap
Cap
Selector G
Driving unit block 100
Pulley dia 26
Washer
Version 04
(translation of the original manual)
Page 20 sur 25
