6. CHANGING THE CHAIN
Take the protecting cover off.
Remove the chain tensioner and the spring.
Tension er
Spring (ref. 120 02 209)
Remove the chain cover ref. 120 02 015.
Chain cover
Space out the motor shaft on the sprocket side.
I02-121 User manual & maintenance guide
Version 02
(translation of the original manual)
of TLM 2000
Page 21 sur 41
