VLT 5000/6000/8000
High Power Installation Guide
Close the doors and connect the power to the VLT frequency converter. The green voltage indi-
cator lamp (ON) on the control panel is activated when the VLT frequency converter receives
voltage.
The VLT frequency converter can now be programmed via the control panel.
Note that in parameter 620
[1]. After cycling the power the parameter is active. This means that without the motor shaft
running you can control the influence of the control signal on the control card.
NOTE: Not a safety function.

6.1.3. Programming Procedures - VLT 5000

Programming the VLT 5000
The frequency converter is programmed over the control panel.
Press [QUICK MENU].
The Quick Menu appears in the display. Choose parameters by means of
Press [CHANGE DATA] to change parameter value. Data values are changed using
Press
→
Press [OK] to save parameter setting.
Set the desired language in parameter 001.
Set motor parameters according to the motor plate:
Motor power
Motor voltage
Motor frequency
Motor current
Rated motor speed
Set frequency interval and ramp times.
Min. reference
Max. reference
Ramp up time
Ramp down time
Set Operation site, parameter 002 for Local.
6.1.4. Programming Procedures - VLT 6000 HVAC, VLT 8000 AQUA
and VLT 4000
The frequency converter is programmed over the control panel.
Press [QUICK MENU].
The Quick Menu appears in the display. Choose parameters by means of
Press [CHANGE DATA] to change parameter value. Data values are changed using
Press
→
Operating mode
Wait at least 20 minutes (D1 and D2 frames) and 46 minutes (E1 frames) before
you open the doors, after the VLT frequency converter has been disconnected from
mains.
or to move the cursor.
→
Parameter 102
Parameter 103
Parameter 104
Parameter 105
Parameter 106
Parameter 204
Parameter 205
Parameter 207
Parameter 208
or to move the cursor. Press [OK] to save your parameter setting.
→
MI.90.J2.02 - VLT ® is a registered Danfoss trademark
Function with de-activated inverter
you can select
↑
↑
6. Start-Up Check
and .
↑
and .
↑ ↑
and .
↑
and .
↑ ↑
