HindlePower AT30 SERIES Operating And Service Instructions page 69

Reference
Designator
F1A/B/C AC Input Fuses
F3/F4
DC Output Fuses
L1
Main Inductor
L2
Optional Filter Inductor
P5
Jumper for disabling Ground Detection circuit
P7
Jumper for voltage selection on A5 pc board
P9
Jumper for front panel lockout feature on A1
R1
Main DC Shunt (25 Adc)
R1
Main DC Shunt (30-100 Adc)
R1 Main DC Shunt (125-400 Adc)
R1
Main DC Shunt (500-800 Adc)
R1
Main DC Shunt (1000 Adc)
R2
Current Rating Resistor
R3
Power Supply (Ballast) Resistor
R4 Positive External Scaling Resistor
R6
Voltage (Crowbar) Resistor
R9
Filter Capacitor (C1) Bleed Resistor
R14
Negative External Scaling Resistor
T1 Main Power Isolation Transformer
Style-5018 input/output/ground terminal
TB1-X
CU-AL compression lug for #14 - 1/0 AWG
Style-5030 input/ground terminal
TB1-AC
CU-AL compression lug for #14 - 1/0 AWG
TB1-DC Style-5030 output terminal
CU-AL comp lug for #6 AWG - 350 MCM
Style-163 input/output/ground terminal
TB1-X
CU-AL comp lug for #6 AWG - 350 MCM
VR1
Output Surge Suppressor (Style-5018)
VR1
Output Surge Suppressor (Style-5030)
VR1
Output Surge Suppressor (Style-163)
VR2/4/5 208/240 Vac Input Surge Suppressor (St-5018)
VR2/4/5 208/240 Vac Input Surge Suppressor (St-5030)
VR2/4/5 208/240 Vac Input Surge Suppressor (St-163)
VR2/4/5 480 Vac Input Surge Suppressor (Style-5018)
VR2/4/5 480 Vac Input Surge Suppressor (Style-5030)
VR2/4/5 480 Vac Input Surge Suppressor (Style-163)
VR3
AC Input Lightning Arrestor
VR6/C4 EMI Output Filter Network (Style-5018)
VR6/C4 EMI Output Filter Network (Style-5030)
VR7/C5 EMI Output Filter Network (Style-163)
Note 1: In older 130 Vdc units, the 500 Ω 50W power supply resistor (R3) mounted to the galvanized base
may be comprised of an assembly of two (2) 250 Ω resistors connected in series.
Note 2: Listed part numbers subject to change without notice. Refer to data listed in AT30 Parts Data
Package report.
Description
SERVICING THE AT30
Factory Part Number
12 Vdc 24 Vdc 48 Vdc
see supplied Parts Data Package
see supplied Parts Data Package
see supplied Parts Data Package
see supplied Parts Data Package
RC0100-00
RC0100-00
RC0100-00
RB0008-13
RB0008-03
RB0008-10
RB0008-18
RB0008-19
see supplied Parts Data Package
RJ0007-26 RJ0035-25 EJ1127-12
12 Ω 2W 68 Ω 11W 150 Ω 50W
RJ0056-48 RJ0056-81 RJ0075-14
3160 Ω 6980 Ω
14.0 kΩ
RJ0063-76 RJ0064-11 RJ0064-41
RJ0028-25 RJ0028-25 RJ0028-27
RJ0074-48 RJ0074-81 RJ0075-14
3160 Ω 6980 Ω
14.0 kΩ
see supplied Parts Data Package
RC0056-18
RC0056-18
RC0056-03
RC0056-03
EJ1132-11
EJ1132-21
EJ1132-31
EJ1132-11
EJ1132-21
EJ1132-31
EJ1132-12
EJ1132-22
EJ1132-32
EJ1074-02
EJ5021-03
EJ5021-04
EJ5021-05
Rec.
Spare
130 Vdc
Y
Y
EJ1127-13
500 Ω 100W
RJ0075-56
38.3 kΩ
RJ0064-80
RJ0036-40
RJ0075-56
38.3 kΩ
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
