Cypress CLUX-4 Operation Manual

1x4 hdmi 1.3 with multi-channels splitter
Hide thumbs

Advertisement

Table of Contents

CLUX-4
1x4 HDMI 1.3 with
Multi-channels
Splitter
Operation Manual
CLUX-4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLUX-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cypress CLUX-4

Summary of Contents for Cypress CLUX-4

  • Page 1 CLUX-4 1x4 HDMI 1.3 with Multi-channels Splitter Operation Manual CLUX-4...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Introduction................2. Features..................3. Operation Controls and Functions.......... 3.1 Front Panel................3.2 Rear Panel................4. Connection and Installation............. 5. Specifications................

  • Page 3: Features

    1. Introduction The HDMI v1.3 Distribution Amplifier Series is the most advanced solution to HDMI signal distribution. Each product in this series is compatible with HDMI v1.3 specifications, a cutting-edge technology which defines the supports to transfer Deep Color (10-bit and 12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high bandwidth up to 225MHz (6.75Gbps).

  • Page 4: Operation Controls And Functions

    OUTPUT INPUT EDID POWER CLUX-4 HDMI V1.3 Splitter HDMI Output 1: Connect output port to the HDMI display. When more than one output connected, the HDMI outputs play identical video signal simultaneously. HDMI Input: Connect input port to the HDMI or DVI output of your source equipment such as DVD player or set-top-box.

  • Page 5: Rear Panel

    3.2 Rear Panel HDMI HDMI HDMI OUTPUT OUTPUT OUTPUT HDMI Outputs 2/3/4: Connect each of the output ports to the HDMI display. When more than one output connected, the HDMI outputs play identical video signal simultaneously.

  • Page 6: Connection And Installation

    4. Connection and Installation HDMI Cable DVD or Set-Top-Box HDTV HDMI display LCD TV 5. Specifications Frequency Bandwidth 2.25Gbps (single link) Input Port 1 x HDMI female port (Type A connector) Output Ports 4 x HDMI female ports (Type A connector) Power Supply 5VDC/2.6A (US/EU standards, CE/FCC/UL certified), center positive...
  • Page 8 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20080403 MPM-CLUX4...
