- Page 1 CMDP-DL2DVI Mini DisplayPort to Dual Link DVI Converter Operation Manual CMDP-DL2DVI...
- Page 2 Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document.
-
Page 3: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
Table of Contents Introduction ……………………..……………………...…..….……. Applications …………………..………………….……....….. Package Contents ………………………...………....… System Requirements ……………..………..………....……. Features …………………………………………..……..…...…… Specifications ………………………………...……..………..…. Operation Controls and Functions ……………...……....…… Top Panel ................. Right Panel .…………………………………..……..…...….… Left Panel .…………………………...………..……..…...….… Connection and Installation ….…………………..…..…..…..Acronyms ….................. -
Page 5: Introduction
1. Introduction The Mini DisplayPort converter is specifically designed to allow Mini DisplayPort source to display on the Dual Link DVI display. Supporting resolutions up to 2560x1600 and ideal for display Mac sources on DVI monitor, this device is powered by USB connection which makes it more convenient to power. 2. -
Page 6: Features
5. Features Compliance with DisplayPort Specification V1.1a at 1.62/2.7Gbps data rate (Low bit rate/High bit rate) Input/output support up to WQXGA (2560x1600 RB60) VESA display format Easy to install and simple to operate No software installation Compact size with elegant design ... -
Page 7: Specifications
6. Specifications Input Ports Mini-DisplayPort Output Ports Dual Link DVI-D Color Space ESD Protection Human body model: ± 10kV (air-gap discharge) ± 6kV (contact discharge) Output TMDS signal 1.2 Volts (peak-to-peak) Dimensions (mm) 210(W) x 91(D) x 30.5(H) Weight(g) Chassis Material Plastic Silkscreen Color Black... -
Page 8: Operation Controls And Functions
7. Operation Controls and Functions The following sections describe the hardware components of the unit. 7.1 Top Panel MDP to Dual-Link DVI Power ① ① Power LED: When the USB cable is connected with power supply this power LED will illuminate in red. 7.2 Right Panel Dual-Link DVI Out... -
Page 9: Left Panel
7.3 Left Panel USB 5V MDP In ① ② ① USB 5V: This cable is to connect to the PC or any USB port with power supply. ② MDP In: This cable is to connect to the Mini DP source equipment such as Mac System PC or NB for input signal. -
Page 10: Acronyms
Acronyms Acronym Complete Term Digital Visual Interface Mini DisplayPort Universal Serial Bus WQXGA Wide Quad eXtended Graphics Array... - Page 12 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20110401 MPM-CMDPDL2DVI...
