Main

1. Press the Menu button on the front
panel or on the IR remote control. The
menu system will be displayed. Select
Setup, then select Main.
The Presets item shows the current
preset (if active). Press the Select
button then use the ▲ or ▼ buttons
to go through the list of presets. Press
Select to recall that preset.
2. Select Routing
gets routed to each Window.
3. Highlight a Window and press the
Select button, then use the ▲ or ▼
buttons to go through the list of inputs.
Press Select to choose routing from
that input.
4. The Audio item shows the current audio
routing. Press the Select button then
use the ▲ or ▼ buttons to go through
the list of inputs. Press Select to
choose audio routing from that input.
5. Use the Power Off
unit into standby. Press Select then
press the ► buttons to highlight Yes.
Press Select again to verify you want to
power down the unit.
to choose which Input
option to put the
page | 25
Menu System
