- Page 1 4x4 HDMI Matrix U S E R M A N U A L www.gefen.com...
- Page 2 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The 4x4 HDMI Matrix is a trademark of Gefen Inc. © 2007 Gefen Inc., All Rights Reserved...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction / Operation Notes Features Panel Layout Using the 4x4 HDMI Matrix RMT16-IR Installation Dip Switch Guidelines IR Codes RS-232 Interface 4x4 HDMI Matrix Rack Mount Diagram Specifi cations Terminology Warranty... -
Page 4: Introduction / Operation Notes
Note: The switching is done by using either the RMT-16-IR remote control or through the RS232 port. The 4x4 HDMI Matrix is rack mountable. Any HDTV with DVI inputs can be connected to the HDMI outputs of the matrix by using a DVI to HDMI adapter if the cable used is DVI. -
Page 5: Features
• HDMI or DVI to HDMI cables are used to connect the inputs and the matrix output • Each display's inputs can be switched with the IR remote control or through RS232 Includes: (1) 4x4 HDMI Matrix (4) HDMI 6 Cables (M-M) (1) 24VDC Power Supply... -
Page 6: Panel Layout
PANEL LAYOUT... -
Page 7: Using The 4X4 Hdmi Matrix
USING THE 4X4 HDMI MATRIX Connect all the sources to the HDMI inputs on the 4x4 HDMI Matrix, using the supplied cables. Connect the HDMI/DVI displays to the outputs on the 4x4 HDMI Matrix. Connect the 24VDC power supply to the 4x4 HDMI Matrix Controlling the 4x4 HDMI Matrix using the RMT16-IR: Pressing Buttons... -
Page 8: Rmt16-Ir Installation
RMT16-IR INSTALLATION 1. Remove battery cover from the back of the RMT16-IR remote. 2. Verify that dip switches 1 & 2 are in the down (OFF) position. 3. Insert the battery, hold the battery so that you can see the positive side facing up. The side that is not marked must be facing down. -
Page 9: Dip Switch Guidelines
DIP SWITCH GUIDELINES Inside the 4x4 HDMI Matrix is a bank of Dip Switches. Below is a table describing their functions. By default, all switches are set to the Off position. Dip Switch # Name Description Switching Delay Adds a 3 second delay to switching... -
Page 10: Ir Codes
4. Dip Switches 1 and 2 in the RMT16-IR correspond with Dip Switches 3 and 4 inside the 4x4 HDMI Matrix respectively. Switch the switches inside the 4x4 HDMI Matrix to match the same Remote Channel as the RMT16-IR. The 4x4 Matrix is now set to a new IR Code. -
Page 11: Rs-232 Interface
RS-232 INTERFACE Binary Table ASCII Corresponding Binary ASCII Corresponding Binary RMT16-IR RMT16-IR Button Button 0011 0001 0011 1001 0011 0010 0110 0001 0011 0011 0110 0010 0011 0100 0110 0011 0011 0101 0110 0100 0011 0110 0110 0101 0011 0111 0110 0110 0011 1000 0110 0111... -
Page 12: 4X4 Hdmi Matrix Rack Mount Diagram
4x4 HDMI MATRIX RACK MOUNT DIAGRAM... -
Page 13: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ................1.65 Gbps Input Video Signal ..................1.2 volts p-p Input DDC Signal ..................5 volts p-p (TTL) Single Link Range ................1080p / 1920 x 1200 HDMI Input/Output Connector ............Type A 19-pin Female Remote Control Port ............RS-232 Female, Mini-Stereo Power Consumption .................. -
Page 14: Terminology
TERMINOLOGY Short form for Display Data Channel. It is a VESA standard for communication between a monitor and a video adapter. Using DDC, a monitor can inform the video card about its properties, such as maximum resolution and color depth. The video card can then use this information to ensure that the user is presented with valid options for confi... -
Page 15: Warranty
Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
