MLC Plus 84 EU and MLC Plus 84 MK • Setup Guide (Continued)

Step 2: Prepare the Installation Site

ATTENTION:
Installation and service must be performed by authorized personnel only.
•
L'installation et l'entretien doivent être effectués par le personnel autorisé uniquement.
•
Extron recommends installing the MLC Plus 84 into a grounded electrical junction box.
•
Extron recommande d'installer le MLC Plus 84 dans un boîtier d'encastrement électrique mis à la terre.
•
If the controller will be installed into fine furniture, it is best to hire a licenced, bonded craftsperson to cut the access
•
hole and perform the physical installation so the surface will not be damaged.
S'il est prévu d'installer le contrôleur dans du beau mobilier, il est préférable de faire appel à un artisan autorisé et
•
qualifié pour couper le trou d'accès et réaliser l'installation de telle façon que la surface ne soit pas endommagée.
Follow all national and local building and electrical codes that apply to the installation site.
•
Respectez tous les codes électriques et du bâtiment, nationaux et locaux, qui s'appliquent au site de l'installation.
•
NOTE: Follow the local and national electrical and building codes that apply to the installation site. In most cases you will
need to use an approved electrical junction box. The end user or installer must furnish the junction box. It is not included
with the MLC Plus 84. Read any installation instructions and regulatory guidelines that come with the mounting devices
(raceway, junction box, surface mounting box) before installing the raceway or box.
Select and prepare the site before cabling the controller. This may include cutting a hole in the installation surface or installing a
cabling raceway, running the cables to that site, installing the wall box, and pulling cables through it.
Accessibility
If applicable, when planning where to install the MLC Plus 84, you may need to consider factors affecting accessibility of the
controller such as height from the floor, distance from obstructions, and how far a user must reach to press the buttons. For
guidelines, see sections 307 ("Protruding Objects") and 308 ("Reach Ranges") of the 2010 ADA Standards for Accessible Design
available at http://www.ada.gov/regs2010/2010ADAStandards/2010ADAStandards.pdf.

Site Preparation

The MLC Plus 84 EU fits a standard two-gang European wall (junction) box or external wall box.
The MLC Plus 84 MK fits a standard two-gang MK-type junction box or external wall box. The installer must provide the box.
Read any installation instructions and regulatory guidelines that come with the wall box before installation. To prepare the site:
For installation into a wall or furniture: Measure, mark, and carefully cut a hole in the mounting surface.
1.
For all types of installations: Run cables
Secure the cables with a clamp for strain relief and so they do not slip back down into the wall or furniture.
2.
Secure the box to the raceway, stud, wall, or furniture.
3.
2
to the
junction box.
