3. Function and operation

After removing the cover, the desired temperature can be adjusted on the
adjustment knob. The thermostat switches from terminal 3 to terminal 5
if the adjusted temperature value is achieved. After adjusting the desired
temperature, the cover has to be mounted again to meet the protective
system IP 65.

4. Survey and technical data

Temperature range
0 up to +50°C
0 up to +200°C
+50 up to +300°C
Technical data:
Voltage:
Breaking capacity:
Frequency:
Nominal current:
Protective class:
Environmental protection:
Working temperature:
Hysteresis:
Accuracy:
Enclosure:
Glands:
Dimensions:
Weight:
Length of capillary tube:
Material of capillary tube:
(Russia, Kazakhstan, Belarus)
For other countries contact your local nVent representative.
Sensor
temperature Max.
+60°C
+230°C
+345°C
230 V AC
16 A / 250 V (contact potential-free)
50 / 60 Hz
16 A
I
IP 65
–20 up to +80°C
2.5% of temperature range
±1,5% of setpoint for temperature
setting in upper third of range
(measured at 22°C)
Polyester
1 x M20 + 1 x M25 incl. reducer M25/M20
122 x 120 x 90 mm
1.2 kg
appr. 2 m
V4A Stainless Steel
Order reference
T-M-10-S/0+50C
T-M-10-S/0+200C
T-M-10-S/+50+300C
nVent.com | 7
