HOME SCREEN/ÉCRAN D'ACCUEIL
1
2
3
5

ITEMS/ AFFICHAGES

Change date and time
Heating indicator - when visible,
4
Pour changer la date et l'heure
system is heating.
Indicateur de chauffage - si visible, le
Current temperature
chauffage est activé
2
Température courante
Access energy use data
5
Target temperature or setpoint
Données d'utilisation énergétique
3
Température visée/point de contrôle
Access Main Menu
6
Pour accéder au menu principal
For detailed information regarding nVent NUHEAT thermostat warranty, please visit nVent.com/NUHEAT/Pour plus de détails sur la garantie du thermostat NUHEAT, consulter nVent.com/NUHEAT.
7

Perform System Tests

Start Using Thermostat

4
8
6
9
GFCI test Button
7
Bouton de test GFCI
GFCI Indicator
8
Indicateur GFCI
On/Off Button
9
Press to turn system ON/Reset GFCI
Hold to turn system OFF
Bouton MARCHE/ARRÊT
Appuyer pour activer système/Réarmer GFCI
Mainenir appuyé pour désactiver système

CLASSIFICATION

The product is a Class II device (enhanced insulation) and must be connected to
the following leads:
Phase L1 (L) 120 V, Phase L2 (N) 0/120 V, Max. load 15 A (resistive load)
The terminals are suitable for field wiring cables of 12 to 22 AWG.
Heating element in accordance with the supply voltage.

TECHNICAL DATA

Supply ...............................................................................120/240 Vac 50/60 Hz
Load ..................................................................................max. 15 A (resistive load)
Power ...............................................................................1800 W at 120 Vac
...........................................................................................3120 W at 208 Vac
...........................................................................................3600 W at 240 Vac
GFCI ..................................................................................Class A (5 mA trip level)
Temperature range ...........................................................+5 to +40°C, +41 to +104°F
Amb. temp. range .............................................................0 to +25°C, +32 to +77°F
Construction of Control: Electronic room thermostat for regulating electrical
underfloor heating.
Method of Mounting Control: Independently mounted control for flush mounting
Type of Action: ..................................................................Type 2.B.
Rated Impulse Voltage : ....................................................2500 V
Control Pollution Degree: .................................................PD2

CERTIFICATION

UL Listed for the US and Canada
According to the following standards:

Thermostat:

UL 60730-1
UL 60730-2-9
CSA E60730-1:13
CSA E60730-2-9
UL file number:
E157297
GFCI:
UL 943 4
ed.
th
CSA C22.2 No. 144.1-06
Patent pending
CLASSIFICATION
Le produit est un dispositif de classe II (isolation améliorée) et doit être branché
aux broches suivantes :
Phase L1 (L) 120 V, Phase L2 (N) 0/120 V, Charge max. 15 A (charge résistive)
Les bornes sont appropriées aux fils de câblage de 12 à 22 AWG.
L'élément chauffant est conforme à la tension d'alimentation.
FICHE TECHNIQUE
Alimentation .....................................................................120/240 Vac 50/60 Hz
Charge ..............................................................................max. 15 A (charge
résistive)
Puissance .........................................................................1800 W à 120 Vac
...........................................................................................3120 W à 208 Vac
...........................................................................................3600 W à 240 Vac
GFCI ..................................................................................Classe A (seuil de
déclenchement 5 mA)Plage de température ...................+5 à +40 °C, +41 à +104 °F
Plage de temp. amb. ........................................................0 à +25 °C, +32 à +77 °F
Construction du dispositif de commande : Thermostat électronique de pièce pour
réguler un plancher chauffant électrique.
Méthode de montage du dispositif : Dispositif de commande à montage
indépendant pour montage encastré
Action de type : .................................................................Type 2.B.
Tension assignée de choc : ..............................................2500 V
Milieu de pollution du dispositif de commande : .............DP2
CERTIFICATION : Homologué UL au Canada et aux États-Unis
Selon les normes suivantes :
Thermostat :
UL 60730-1
UL 60730-2-9
CSA E60730-1:13
CSA E60730-2-9
Numéro de dossier UL :
EE157297
GFCI :
UL 943 4
éd.
e
CSA C22.2 No. 144.1-06
Brevet en instance
HOME
nVent NUHEAT Home Quick Start Guide
Guide De Démarrage Rapide - NUHEAT Home
Perform System Tests
Start Using Thermostat

WARNINGS:

To avoid electric shock, disconnect the heating system power supply at the
main panel before installation and maintenance of the thermostat. Keep
thermostat air vents clean and free from obstruction. This thermostat is an
electrical product and must be installed in compliance with the National
and/or Local Electrical Code. Installation must be performed by qualified
personnel where required by law.
AVERTISSEMENTS :
Pour éviter une décharge électrique, coupez l'alimentation du système de
chauffage au panneau de distribution avant l'installation et/ou l'entretien du
thermostat. Gardez toujours les évents du thermostat propres pour éviter
les obstructions. Ce thermostat est un produit électrique et doit être installé
conformément aux codes nationaux et locaux de l'électricité. Lorsque la loi
l'exige, le thermostat doit être installé par du personnel qualifié.
NORTH AMERICA AMÉRIQUE DU NORD
Tel. Numéro sans frais
+1.800.545.6258
Fax Télécopieur
+1.800.527.5703
thermal.info@nvent.com
©2018 nVent. All nVent marks and logos are owned or licensed by nVent Services GmbH or its affiliates. All other
trademarks are the property of their respective owners. nVent reserves the right to change specifications without notice.
Nuheat-IM-H59313-HomeThermostatProg-EN-1805
