Technical data

12.1 Torques

(The torques are valid for the aluminum and stainless steel
316 variants)
Part Torque Lb. In.
Housing cover
Sensors
Plug
Cable bushing
Device to e-Box
If an optional e-Box is being used, fasten the device securely
to the e-Box with 4 screws and a tightening torque of 8 Nm.
12.2 Tightening torque and cable size for field
wiring terminals
Terminals Torque Lb. In.
Power
4.4 – 7.0
supply and
(0.5 – 0.8 Nm)
signal
4.4 – 7.0
Relay
(0.5 – 0.8 Nm)
32
Torque Nm
min. 266 min. 30
min. 266 min. 30
min. 266 min. 30
min. 443 min. 50
71 8
Cable size in Cable size in
AWG mm
24 – 12 0.2 – 2.5
20 – 12 0.5 – 2.5

12.3 Factory settings

12.3.1 Alterable settings for the Polytron 8000
Menu
A1 Alarm
A2 Alarm
A1 Relay alarm:
Direction
A2 Relay Alarm:
Direction
A1 latching mode
A2 latching mode
A1 Acknowledgement mode
A2 Acknowledgement mode
A1 enrg / wired in e-Box
A2 enrg / wired in e-Box
2
Calibration password
LCD setting
Configuration password
SIL status
Language
Fault current
Warning current
Warning
Maintenance current
HART address
Auto-cal.
Calibration interval
Function key
Standard setting
Depending on the sensor
Rising
(falling with DrägerSensor O
Rising
Non-latching
Latching
Acknowledgeable
Not acknowledgeable
Energized / NO
Energized / NO
_ _ _1
On
_ _ _2
Off
English
1.2 mA
3.0 mA
Off
3.4 mA
0
Off
Depending on sensor
Faults
Dräger Polytron 8000
)
