Settings menu
8.5

Datalogger

The datalogger has a
3000 measurements. At a sampling interval of 1 minute,
this would allow monitoring for approx. 50 hours. The monitoring
time can be significantly increased if the Trigger function
is enabled.
The results in the datalogger can only be evaluated with the
PolySoft 8000 PC software. An evaluation of the datalogger
contents over the last 15 minutes is available in the menu
under Information > Datalogger > Graph (see chapter 7.3.2
on page 18).
8.5.1 Switching the datalogger on or off
1. Select Settings > Datalogger > Datalogr. on/off and
confirm.
2. Select On or Off and confirm.
8.5.2 Setting up the datalogger
Setting the sampling interval
1. Select Settings > Datalogger > Datalogr. on/off >
Sample time and confirm.
2. Select the sample time and confirm.
Setting peak/average
1. Select Settings > Datalogger > Set datalogger > Peak/
average and confirm.
2. Select the desired function and confirm.
Peak value The measured maximum value (for O
minimum value) of the concentration within
the selected sampling interval is stored.
Average The average value of all the concentrations
measured within the selected sampling time
is stored.
26
storage capacity of approx.
2
Switching the trigger on or off
1. Select Settings > Datalogger > Set datalogger > Trigger
on/off and confirm.
2. Select On or Off and confirm.
On Concentrations will only be stored if they
exceed (relative to the last stored value)
a threshold set under Trigger Value.
Off The measurements made within the set
sampling time are always stored.
Setting the trigger threshold
The trigger threshold is specified as a percentage of the
maximum range.
Example: A trigger threshold of 2 % is entered for a maximum
range of 500 ppm. Consequently the datalogger will only store
measurements if they deviate (relative to the last stored value)
by 10 ppm.
1. Select Settings > Datalogger > Datalogr. on/off >
Trigger value and confirm.
2. Set the trigger value and confirm.
Setting the storage mode
1. Select Settings > Datalogger > Set Datalogger > Stack/
Roll and confirm.
2. Select the desired condition and confirm
Overwrite
, the
Hold
8.5.3 Clearing the datalogger
1. Select Settings > Datalogger > Clear Datalogr. and confirm.
2. To clear the datalogger, select Confirm and confirm.
When the capacity of the datalogger is
used up, the older data will be overwritten.
When the capacity of the datalogger is
used up, no more data can be stored.
An appropriate warning is issued.
